Name Description Torque渊N窑m冤
Cylinderheadbolt M11伊127-4h 105依5
Crankshaftinstallingbolt M12伊1.5伊47 110依10
IdlegearAinstallingbolt M8伊55 25依5
IdlegearAinstallingbolt M12伊1.25伊66 110依10
Exhaustmanifoldinstallingbolt M8伊35 30依5
Connectingrodbolt M11伊1.25 85依5
Dampedbeltinstallingbolt M16伊1.5伊29 210依15
Mainbearinghousinginstallingbolt M14伊1.5伊89 170依10
Flywheelbaffleinstallingbolt M12 85依10
Flywheelinstallingbolt M13伊1.25伊36.5 120依10
Cylinderheadcoverinstallingbolt M8伊11 13依5
Rockerinstallingbolt M10 55依5
5
郁.MainBoltandnuttorque
HFC4DA1andHFC4DA1-1
Mode
Valveclearance
Oilpressure渊idle冤
Exhausttemperature(mainpipe)
Oiltemperature(mainoilgallery)
Temperatureofthermostat
Temperatureoffull-openthermostat
Projectedheightofglowplug
Projectedheightofinjector
Staticfuelsupplyadvancedangle
(beforetopdeadcenter)
HFC4DA1-1 HFC4DA1
0.3耀0.4mm 0.3耀0.4mm
逸98kpa 逸98kpa
臆650益 臆700益
臆130 益 臆130 益
82益 82益
95益 95益
5.3耀6.8mm 5.3耀6.8mm
2.1耀3.0mm 3.7耀4.3mm
12毅
HFC4DA1-2B HFC4DA1-2B1
0.3耀0.4mm 0.3耀0.4mm
逸98kpa 逸98kpa
臆700益 臆700益
臆130 益 臆130 益
82益 82益
95益 95益
5.6耀6.9 5.6耀6.9
2.1耀3.0 2.1耀3.0
16毅
4
芋.Maincheckingandadjustingparameters
OWNER爷SMANUAL
2.8LSeriesDieselEngine
