ETACS
ETACS
ETACS
ETACS Pin
Pin
Pin
Pin Definition
Definition
Definition
Definition (Continued)
(Continued)
(Continued)
(Continued)
Port No. Port Name Input/Output Initial Status Operating Status Remark
A24 V ehicle speed signal Input NC Pulse
B1 D river side door switch Input NC Low level
B2 R ear fog lamp switch Input NC Low level
B3 Left/right front window relay Output NC Low level
B4 F ront water sprayer switch Input NC Low level
B5
Front passenger side door lock
switch
Input NC Low level
B6 H and brake switch Input NC Low level
B7 R ear defroster switch Input NC Low level
B8 F ront fog lamp switch Input NC Low level
B9 IG2 Input NC High level
B10 Door switch Input NC Low level
B11 K ey insertion switch Input NC High level
B12 H eadlamp switch Input NC Low level
B13 S mall lamp switch Input NC Low level
B14 Driver side door lock switch Input NC Low level
B15 Middle door locking device Input NC ( locked ) Low level ( unlocked )
B16 S eat belt switch Input NC Low level
B17 Storage code Input NC Pulse
B18 IG1 Input NC High level
B19 F ront wiper intermittent switch Input NC Low level
B20
B21 Airbag signal Input NC Low level
B22 Front wiper interval adjustment Input
B23 Generator L Input NC High level
B24 External antenna
