Maintenance manual for sunray hfc4da1-2c china-IV diesel engines
66
section passage is greatly higher than that passing through the constant section passage.
Idling of
engine
Small passage
section
Large passage
section
High speed
running of engine
Rotation direction of adjustment ring
