Inspectbrakingliquidlevel
Brakingliquid
Itisrecommendedtousethehy鄄
draulicbrakingliquidinconjunction
with"JG4".Refertotherelevantin鄄
structionsonthecontainer.
Inspectthelevel
Thebrakingliquidinthebrakingliq鄄
uidtankshouldbeinspectedperi鄄
odically.Thelevelshouldbebe鄄
tweenthe"MIN"and"MAX"markson
thesideofthetank.Ifthelevelisat
orbelowthe"MIN"mark,addbrak鄄
ingliquidtothe"MAX"position.
音 Neverfillupexcessively.
Inspectclutchliquid
Inspectionmethodofclutchliq鄄
uid
Toservicetheenginehood,itisnec鄄
essarytoinspecttheclutchliquid
levelofthegeneralbrakingpump.
Thesystemshouldalsobechecked
openoverthespecifiedtimeperi鄄
od.Thiscanpreventdamageto
thebrakesystembyintrusionof
dirtandmoisture.
Maintenancebyvehicleowner
120
Warning院
音 Brakingliquidspilledintoyour
eyesmayaffectyoursight.Use
qualifiedDOT3orDOT4braking
liquid.Neverleavethebrakingliq鄄
uidreservoirorbrakingliquidtank
Warning院
音 RefertothecontentsinCau鄄
tionwhenmeasuringthebraking
liquidlevel.Brakingliquidspilled
intoeyesmaycausesightdete鄄
rioration.Itcanalsodamagethe
paintandbrakingliquidisnot
readilyremovable.
forpossibleoilleakage.Checkand
confirmthattheclutchlevelisbe鄄
tween"MAX"and"MIN".Addasuit鄄
ableamountofclutchliquidasre鄄
quired. Decrease of level means
leakageexistingintheclutchsystem,
andatimelyinspectionshouldbe
madetoidentifytheleakingposition
andhaveitrepaired.Consultyour
JAC dealer for detailed repair
method.
Replacebrakingliquid
TherecommendedJG4brakingliq鄄
uidshouldbeused.
The cap of braking liquid fluid
reservoirmustbetightlyclosed,to
preventdirtandmoisturefromenter鄄
ing.
Maintenanceofairconditioner
Keepthecondenserclean
Checkperiodicallytheaircondition鄄
ingcondenser (andengineradiator)
foraccumulateddirt,deadinsects
andleaves.They may affectthe
cooling effect. Take care when
cleaningsuchobjectstoavoidbeing
trappedintothecoolingfan.
Inspectthedrivingbeltofair
conditioningpump
Whentheairconditionerisinnormal
use,theairconditioningpumpdriv鄄
ingbelttensionshouldbechecked
onceamonth.Tocheckthetension
ofthisbelt,pressthebeltinthemid鄄
dlebetweentheenginecrankshaft
andairconditioningpumppulley.
The deflection must not exceed
8.0mmwhenitispressedwithafin鄄
ger.Thedeflectionmayapproach
8.0mm (0.315ft)whenmeasured
withinstrumentatapressureof98N
Note:
音 Neverallowotherliquidto
contaminatethebrakingliquid.
This may render the system
functioningabnormal.
121
Warning院
音 RefertothecontentsinCau鄄
tionwhenmeasuringthebraking
liquidlevel.Brakingliquidspilled
intoeyesmaycausesightdete鄄
rioration.Itcanalsodamagethe
paintandbrakingliquidisnot
readilyremovable.
