序号
NO.
注解 件号
Note Part NO.
名称
Description
数量
Qty
1
40211031
机壳侧盖
FRAME SIDE COVER 1
2 402S11001
螺钉
SCREW
3
3 402S11003
螺钉
SCREW 1
4 40202001
机头支撑臂
MACHINE ARM SUPPORT ROD 1
5 402S11002
螺钉
SCREW 1
6 40226001
弹性圆柱销
PIN 1
7 40222001
橡胶缓冲垫
RUBBER CUSHION 1
8
40212111
侧盖板
SIDE COVER 1
9 40222002
侧盖板衬垫
SIDE COVER GASKET 1
10 402S11003
螺钉
SCREW 7
11 40201001
机壳侧盖
FRAME SIDE COVER 1
12 402S11031
螺钉
SCREW 2
13 402S30001
螺钉
SCREW 1
14 40222003
缓冲垫
CUSHION 2
19 40212105
挑线杆防护罩
THREAD TAKE-UP LEVER OIL GUA
R
1
20 402S11004
螺钉
SCREW 2
21 40201064
面板
FACE COVER COMPLETE 1
21-1 40222005
面板塞
FACE COVER COMPLETE PLUG 1
21-2 402S11036
螺钉
SCREW 1
21-3 40228008
垫片
SPACER 1
22 40222038
面板衬垫
GASKET 1
24 402S11031
螺钉
SCREW 4
25 40222007
油封
OIL SEAL 2
27 40201061
顶盖
TOP COVER 2
34 40212003
齿轮箱盖
GEAR CASE COVER 1
35 40228001
碟形垫片
DISC SPRING 1
36 402S20001
轴位螺钉
HINGE SCREW 1
38 40212004
手制动钩
HAND STOP LATCH 1
39 402S11014
螺钉
SCREW 2
40 402S11001
螺钉
SCREW 6
43 40222009
橡胶插塞
RUBBER PLUG 1
44 40222037
上顶盖衬垫
TOP COVER GASKET REAR 1
47 40203001
停刀杆轴导向
管
KNIFE STOP LEVER SHAFT GUIDE 1
48 40222011
橡胶插塞
RUBBER RLUG 3
49 40222012
右侧盖板衬垫
SIDE COVER GASKET 1
50 40212098
左侧盖板
SIDE COVER 1
51 402S11003
螺钉
SCREW 7
52 40222013
油视窗衬垫
GASKET 1
53 40212006
侧盖
SIDE COVER 1
54 402S11003
螺钉
SCREW 4
55
40211032
侧盖板
SIDE COVER 1
56 402S11003
螺钉
SCREW 2
57 40212007
推板
BED SLIDE 1
58 403S11001
螺钉
SCREW 1
59 40227041
推板簧
BED SLIDE SPRING 1
60 402S30003
底板支撑螺钉
BED SCREW STUD 2
61
40230011
LED灯
LED 1
62 41312003
线夹
CABLE CLAMP 4
63 40112091
线夹
CABLE CLAMP 3
64 40211003
油视窗
OIL SIGHT WINDOW 1
65 40222014
油视窗垫片
OIL SIGHT WINDOW GASKET 1
67 40222016
盲孔塞
RUBBER PLUG 5
68 40223001
油毡
OIL FELT 2
70
40211034
电机侧盖
MOTOR SIDE COVER 1
71 413S13003
螺钉M4×6
SCREW 2
72 413S13019
螺钉M5×12
SCREW 1
73
402S30062
柱塞螺钉
SCREW 1
74
402S16006
螺母
NUT 1
- 2 -
7
6
4
0913009
导
线钩
W
IRE HOOK
1
