序号 注解 件号 数量
NO. Note Part NO. Qty
1 40226002
铰链销 HINGE STUD
1
2 402S14001
螺钉 SCREW
1
3 12923018 油线 OIL WICK 1
4
--------
0
5
--------
0
6
--------
0
7
--------
0
8 40202054 上轴 MAIN SHAFT 1
10
--------
挑线连杆 THREAD TAKE UP CRANK
11
4023800200
挑线杆组件 LINK TAKE UP
12 40204001 针杆曲柄 NEEDLE BAR CRANK 1
13 40205001 针杆曲柄连杆 NEEDLE BAR CRANK CONNECTING ROD 1
14
--------
滚针轴承 NEEDLE BEARING 2
15 402S30004 左旋螺钉 END SCREW LEFT 1
16
--------
0
17 40228002 止推垫圈 THRUST WASHER 1
18 402S30005 螺钉 SCREW 1
19 40204002 平衡块 COUNTER WEIGHT 1
20 402S14002
螺钉 SCREW
2
21
--------
0
22 101S11003 螺钉
SCREW
1
23 B04009 轴承 BALL BEARING 1
24 40203003 轴套 BALL BEARING 2
25 H03012 挡圈25 THRUST COLLAR 1
26 B07016 滚动轴承 ROLLER BEARING 1
27 40205002 刀杆驱动连杆 KNIFE BAR DRIVING CONNECTING ROD 1
28 40210001 刀杆传动偏心凸轮 KNIFE BAR DRIVING ECCENTRIC CAM 1
29 B02004 轴承 BALL BEARING 1
30 402S14006 螺钉 SCREW 6
30-1 409S14001 螺钉 SCREW 2
31
--------
0
32 402S14003 螺钉 SCREW 2
33 40225001 蜗杆 WORM 1
34
--------
0
35 4023503000 同步带轮组件 SHAFT SPROCKET 1
36 40235003 同步带 TIMING BELT 1
37 40224006 轴承 BEARING 1
38
--------
联轴器 1
38-1 40201063 联轴器传动块1 COUPLING 1 1
38-2
40201069
联轴器传动块2 COUPLING 2 1
38-3
40222040
减震橡胶 DAMPING RUBBER 1
39 40235027 手轮 HAND WHEEL 1
40 40230001 主轴电机 SERVO MOTOR 1
41
413S13012
电机安装螺钉 SCREW 4
42 40235028 绕线轮 BOBBIN WINDER DRIVING WHEEL 1
43 402S15006 绕线轮螺钉 SCREW 2
44
S09002
螺钉 SCREW 6
45 207S14006 螺钉 SCREW 2
46
W01013
平垫片 WASHER 4
47 40128026 弹簧垫片 SPRING WASHER 4
名称 Description
