序号 注解 件号 数量
NO. Note Part NO.
Q
t
y
1 4021800100 梭壳组件 BOBBIN CASE ASM. 1
10 4021800200 梭子 BOBBIN 1
11 4021800500 旋梭套组件 HOOK C ASM. 1
12 40212010 梭壳定位板 BOBBIN CASE POSITIONING PLATE 1
13 402S11006 螺钉 SCREW 2
14 4020300700 旋梭筒组件 OIL SLEEVE ASM. 1
15
101S14001
螺钉 SCREW
4
16
40123016
油线 OIL WICK 1
17 N01008 螺母 NUT 1
18 40228002 垫圈 THRUST WASHER 1
19 40203009 下轴前套 BUSHING ASM 1
20
12923018
油线 OIL WICK 2
21
--------
0
22 40225002 蜗杆 WORM LEVER 1
23 40225003 小齿轮 PINION 1
24 201S14002 螺钉 6
25 H01009 挡圈 1
26 B04012 轴承 1
27
0
28
SCREW
THRUST COLLAR
BALL BEARING
0
29 4023500700 小皮带链轮组件 BELT SPROCKET 1
30 40224004 轴承 BALL BEARING 1
31 40208001 轴承固定挡圈 COLLAR 1
32 20628006 垫圈 WASHER 1
33 402S13001 内六角平头螺钉 SCREW 1
34 S05038 螺钉 SCREW 1
35 H01009 挡圈 THRUST COLLAR 1
36 B04012 轴承 BALL BEARING 1
37 40235008 皮带张紧轮 TENSION PULLEY 1
38 40226005 调节杠杆针 ADJUSTING LEVER PIN 1
39 40205023 张紧轮连杆 TENSION PULLEY LINK 1
40 40212102 调节配件 ADJUSTING GUIDE 1
41 40204037 连接接头 CONNECTOR 1
42 40228031 垫片 SPACER 1
43 40226051 连接销 CONNECTION PIN 1
44 40205024 调节连杆 ADJUSTING LINK 1
45 40212103 固定板 FIXED PLATE 2
46 40223005 油毡 OIL FELT 2
47 402S30009 旋梭调节润滑螺钉 HOOK OIL ADJUSTING SCREW 1
48 402S16002 螺母 NUT 1
49
40221012
油管 OIL TUBE 0
50
40209002
调节润滑螺钉座 OIL ADJUSTING SCREW BASE 1
51 40221004 调节润滑螺钉座架 OIL ADJUSTING SCREW BRACKET 1
52 402S11004 十字槽盘头螺钉 SCREW 2
53 40202039 下轴 HOOK DRIVING SHAFT 1
54 40226006 调节销 ADJUSTING PIN 1
55 402S16026 调节螺母 NUT 1
56 40208014 挡圈 THRUST COLLAR 1
57 41303002 挡圈 THRUST COLLAR 1
58 413S14004 螺钉 SCREW 2
59 S05004 固定板安装螺钉 SCREW 2
60 403S14017 螺钉 SCREW 1
名称 Description
- 6 -
--------
--------
