序号 注解 件号 数量
NO. Note Part NO.
Q
t
y
1 4021500100 剪底线器组件 BOBBIN THREAD TRIMMER ASM. 1
2 40215002 针板组件 NEEDLE PLATE 1
3 402S17001 螺钉 SCREW 2
4 4021500300 针板座组件 THROAT PLATE BASE 1
5 4021900500 剪底线动刀 BOBBIN THREAD TRIMMER 1
6 402S30023 螺钉 SCREW 1
7 40219007 底线切刀固定刀 COUNTER KNIFE 1
8 402S11016 螺钉 SCREW 2
9 40204016 底线切刀杆 BOBBIN THREAD TRIMMER LEVER 1
10 402S11017 螺钉 SCREW 1
10-1 40228009 垫圈 WASHER 1
11 40219008 底线拉杆 BOBBIN THREAD PULLER 1
12 402S11018 螺钉 SCREW 2
13 402S11030 螺钉 SCREW 4
13-1 402S11036 螺钉 SCREW 1
14 40227012 压板 PRESSER PLATE 1
15 40212044 剪底线连杆 BOBBIN THREAD TRIMMER LINK 1
16 402S20012 铰链螺钉 SCREW 1
17 40227013 底线导向板 BOBBIN THREAD GUIDE 1
18 402S11022 螺钉 SCREW 2
19 40205008 剪底线传动杆 BOBBIN THREAD TRIMMER DRIVING LEV
E
1
20 402S20013 螺钉 HINGE SCREW 1
21 40210004 套筒 SLEEVE 1
21-1 S05042 螺钉 SCREW 1
22
--------
剪线底传动杆 0
23
--------
套筒 0
24
--------
铰链销螺钉杆套筒 0
25
--------
剪底线传动杆 0
26
--------
套 筒 0
27
--------
螺钉 0
28
-------- 剪底线传动杆连杆
0
29
--------
螺钉 0
30 402S16003 螺母 NUT 1
31
--------
0
32 40205019 凸轮连杆 CONNECTING LINK 1
33 402S30058 止动限位螺钉 STOP SCREW 1
34 402S16008 螺母 NUT 1
35 40226026 铰链螺栓 HINGE STUD 1
36 402S14001
内六角凹端紧定螺钉 SCREW
1
37 40205010 底线剪刀驱动杆 BOBBIN THREAD TRIMMER DRIVING ARM 1
38 402S20014 轴位螺钉 HINGE SCREW 1
39 402S30025 球形螺钉 BALL SCREW 1
40 402S16003 螺母 NUT 1
名称 Description
- 16 -
