Jack JK-T718E - Page 66

序号 注解 件号 数量
NO. Note Part NO.
Q
t
y
1
--------
0
2 40223017 回油毡 OIL RETURN FELT 1
3 40221003 回油管 OIL RETURN TUBE 1
4 40212071 油管压板 CABLE HOLDER 1
5 402S11003 螺钉 SCREW 1
6
--------
0
7
--------
0
8
--------
0
9
--------
0
10
402S11003
螺钉 SCREW 2
10-1 206S11002 螺钉 SCREW 5
11 4021207300 盛油盘组件 OIL RECEIVER 1
12
40209026
调节润滑螺钉座 OIL ADJUSTING SCREW BASE 1
13 4022000100 油泵座组件 OIL PUMP 1
14 40225012 油泵驱动蜗轮 OIL PUMP DRIVING WORM GEAR 1
15
201S14002 SCREW 2
16
S05003
螺钉M5×10 SCREW 2
17
--------
油毡导架 OIL FELT GUIDE 0
18
--------
螺钉 SCREW 0
19
--------
油量调节螺钉 HOOK OIL ADJUSTING SCREW 0
20 40227035 弹簧 SPRING 1
21 40212076 油泵板 OIL PUMP PLATE 1
22
--------
0
25
40212108
油罩 OIL SHIELD 1
26 40212078 油罩 OIL SHIELD 1
27 40212079 油罩 OIL SHIELD 1
47 40201066 油盘 OIL RESERVOIR 1
49 40222026 橡胶缓冲垫 RUBBER CUSHION 4
50 402S11003 螺钉 SCREW 4
51 40201020 铰链座300849 HINGE HOLDER 2
52
P03031
销P6×28 PIN 2
53 S05016 螺钉M6×25 SCREW 4
53-1 40128026 弹簧垫圈 SPRING WASHER 4
54 40228014 垫圈 WASHER 4
55 402S11026 螺钉 SCREW 1
56 40222027 垫片 1
68
--------
拔叉传动销 0
69
--------
橡胶套 0
70 40222028 油盘缓冲垫 MACHINE BASE FELT PAD 4
71 402S30048 油盘螺栓 MACHINE BASE SCREW STUD 4
72 40228019 垫圈 WASHER 4
77 40226039 连接销 CONNECTION STUD 2
77-1 40222031 橡胶垫圈 RUBBER WASHER 2
78
--------
油池 0
79
--------
O型环 0
80 40212081 PIPE RETAINER 1
80-1 206S11002 SCREW 2
86 40212082 PIPE GUIDE 1
86-1 206S11002 SCREW 2
87
40212099
油管固定板
螺钉
油管导架
螺钉
油线固定夹
OIL WICK LATCH 1
88
20626004
油线销 OIL WICK PIN 1
89 401S16002 螺母 NUT 4
名称 Description
90
91
92
40212106
40223024
413S13016
挡油板
油毡
螺钉
OIL BAFFLE
OIL FELT
SCREW
1
1
2
