序号
注解
件号
数量
NO. Note Part NO.
Q
t
y
1 40211001 机头侧盖 FRAME SIDE COVER 1
2 402S11001 螺钉 SCREW 1
3 402S11003 螺钉 SCREW 1
4 40202001 机头支撑臂 MACHINE ARM SUPPORT ROD 1
5 402S11002 螺钉 SCREW 1
6 40226001 弹性圆柱销 PIN 1
7 40222001 橡胶缓冲垫 RUBBER CUSHION 1
8 40212001 侧盖板 SIDE COVER 1
9 40222002 侧盖板衬垫 SIDE COVER GASKET 1
10 402S11003 螺钉 SCREW 7
11 40201001 机壳侧盖 FRAME SIDE COVER 1
12 402S11031 螺钉 SCREW 2
13 402S30001 螺钉 SCREW 1
14 40222003 缓冲垫 CUSHION 2
15 -------- 0
16 -------- 0
17 -------- 0
18 -------- 0
19
40212105
挑线杆防护罩 THREAD TAKE-UP LEVER OIL GUARD 1
20 402S11004 螺钉 SCREW 2
21 40201064 面板 FACE COVER COMPLETE 1
21-1 40222005 面板塞 FACE COVER COMPLETE PLUG 1
21-2
402S11036
螺钉 SCREW 1
21-3 40228008 垫片 SPACER 1
22 40222038 面板衬垫 GASKET 1
23 -------- 0
24 402S11031 螺钉 SCREW 4
25 40222007 油封 OIL SEAL 2
27 40201061 顶盖 TOP COVER 2
29 -------- 0
30 -------- 0
33 -------- 0
34 40212003 齿轮箱盖 GEAR CASE COVER 1
35 40228001 碟形垫片 DISC SPRING 1
36 402S20001 轴位螺钉 HINGE SCREW 1
38 40212004 手制动钩 HAND STOP LATCH 1
39 402S11014 螺钉 SCREW 2
40 402S11001 螺钉 SCREW 6
41 -------- 0
42 -------- 0
43 40222009 橡胶插塞 RUBBER PLUG 1
44 40222037 上顶盖衬垫 TOP COVER GASKET REAR 1
45 -------- 0
46 -------- 0
47 40203001 停刀杆轴导向管 KNIFE STOP LEVER SHAFT GUIDE 1
48 40222011 橡胶插塞 RUBBER RLUG 3
49 40222012 右侧盖板衬垫 SIDE COVER GASKET 1
50 40212098 左侧盖板 SIDE COVER 1
51 402S11003 螺钉 SCREW 7
52 40222013 油视窗衬垫 GASKET 1
53 40212006 侧盖 SIDE COVER 1
54 402S11003 螺钉 SCREW 4
55 40211002 侧盖板 SIDE COVER 1
56 402S11003 螺钉 SCREW 2
57 40212007 推板 BED SLIDE 1
58 403S11001 螺钉 SCREW 1
59 40227041 推板簧 BED SLIDE SPRING 1
60 402S30003 底板支撑螺钉 BED SCREW STUD 2
61 40330025 LED灯 LED 1
62 41312003 线夹 CABLE CLAMP 4
63 40112091 线夹 CABLE CLAMP 3
64 40211003 油视窗 OIL SIGHT WINDOW 1
65 40222014 油视窗垫片 OIL SIGHT WINDOW GASKET 1
67 40222016 盲孔塞 RUBBER PLUG 5
68 40223001 油毡 OIL FELT 2
名称 Description
0B
-2-
