JACKED UP JUF-PR2 - Page 31

KEY NO. PART DESCRIPTION SPEC QTY
PARTS LIST
106 Bushing
φ25×φ21.8×φ12.2×8
6
107 Bushing
φ38×φ34×φ27×26
8
108 End Cap φ25 18
109 End Cap
□
□□
□
50
3
110 End Cap φ28 4
111 End Cap
□
□□
□
40×50
1
112 Hook φ8 4
113 Bent Washer 20×R20×φ9 2
114 Hex nuts M12 2
115 Allen Bolt M6×10 30
116 Allen Bolt M8×25 4
117
Hexagon socket countersunk head screws
M8×20 2
118
He
xagon socket countersunk head screws
M6×12 18
119 Allen Bolt M12×30 2
120
Hexagon socket button head screws
M8×16 2
121
He
xagon socket button head screws
M6×30 4
122
Hexagon socket button head screws
M5×25 2
123 A
llen Bolt M8×16 8
124 Set screw M8×8 2
125 Carriage Bolt M10×70 12
126
Hexagon socket button head screws
M10×65 2
127 N
ut M10 2
128 HEX Bolt M10×90 8
129 Allen Bolt M10×38 2
130 HEX Bolt M10×45 14
131 HEX Bolt M10×25 16
132 Allen Bolt M10×16 4
133 HEX Bolt M10×75 24
134 HEX Bolt M10×35 2
135 HEX Bolt M10×65 6
136 HEX Bolt M10×105 2
137 HEX Bolt M10×95 8
138 HEX Bolt M12×90 1
139 HEX Bolt M12×95 2
140 HEX Bolt M12×25 22
30
