24
Back view
1. Battery compartment
2. RESET: Reset the unit to the default settings
3. DISPLAY LOCK (ON / OFF): Select / deselect the display screen
(bar chart / digits) as default
Description of the multi sensor
Front view
1. Indicates AM / PM (only in UK time mode)
2.
Indicates which channel has been set
3.
Sensor battery low
4. Clock
5. Temperature
Back view
1. RESET: Reset the unit to the default settings
2. SEARCH: Disable / enable the radio control signal
3. °C / °F button (EU version: °C / US version: °F)
4. Battery compartment
5. EU / UK switch (radio controlled clock)
6. Channel switch
Getting started
To set up the multi sensor
1. Unscrew the four screws securing the battery
cover and insert the battery matching the
poles (+/-). On initial set-up, simply remove
the plastic strip in the battery compartment.
2. Select a channel and press RESET.
3. Replace the battery cover and tighten the
four screws.
4. Place the sensor and make sure that the signal is
transmitted and received without interference.
Note:
Use alkaline batteries for longer usage, and lithium batteries
in temperatures below freezing.
Note:
Install the battery in the sensor before the main unit.
Mounting of the multi sensor
The sensor is designed to be either free-standing or to be mounted on
the wall using the mounting plate, (see p. 33). When the mounting plate
is fixed, mount the sensor on the hooks and slide down the sensor until a
"click" is heard.
