11
> Change from previous revision
AR331
Item Part No. Qty. Description Serial Numbers/Notes
1
128079 1 Rod End, 1/4 ”
2 3003474 1 Reverse Pedal Grip
3 3003475 1 Forward Pedal Grip
4 4185740 2 Pedal Pivot Bracket Fitted Assembly
5 4185741 1 • Self Align Bearing, 1/2 ”
6 4185742 1 • Bracket - Pedal Pivot
7 4377886 1 Mow Mode Bracket
8 4378832 1 Pedal
9 450001 1 Hex Head Bolt, M6 - 1.0 x 30 MM LG
10 450014 1 Hex Head Bolt, M8 - 1.25 x 30 MM LG Grade 8.8
11 450020231 1 Hex Head Thin Nut, 1/4 - 28
12 450172 6 Hex Head Screw, M6 - 1 x 25 MM LG
13 450192 4 Hex Head Screw, M8 - 1.25 x 25 MM LG
14 450324 3 Hex Head Nut, M8 - 1.25
15 450333 1 Hex Head Nut, M12 - 1.75
16 450377 1 Hex Head Nut, M6 - 1.0
17 450389 9 Washer, M6 x 12.5 x 1.8
18 450390 8 Washer, M8 x 17 x 1.8
19 452435 6 Hex Head Flange Nut, M6
20 450193 2 Hex Head Screw, M8 - 1.25 x 30 MM LG Grade 8.8
21 450199 2 Hex Head Screw, M8 - 1.25 x 60 MM LG Grade 8.8
22 450200 1 Hex Head Screw, M8 - 1.25 x 65 MM LG Grade 8.8
23 452436 7 Hex Head Flange Nut, M8
24 670804 1 Mow Mode Player
25 670806 1 Transmission Pedal Baseplate
26 672014 1 Traction Lever Weldment
27 4200040 1 Detent Screw, M12
28 UK450511 2 Pan Head Screw, M3 - .5 x 25 MM LG Grade 4.8
29 UK450386 4 Washer, M3 x 7 x 0.6
30 4125831 1 Proximity Switch
31 UK452436 2 Flanged Hex Nut, M3 - 0.5 Grade 8
32 671379 1 Mounting Plate Proximity Switch (Not Shown)
33 UK450192 2 Hex Head Screw, M8 - 1.25 x 25 MM LG
34 UK450390 6 Washer, M8 x 17 x 1.8
35 UK450191 2 Hex Head Screw, M8 - 1.25 x 20 MM LG
36 UK450411 2 Lock Washer, M8 x 12.75 x 2
37 674526 1 Strike Plate Bump Stop
38 UK450378 2 Hex Nut, M8 - 1.25
