en-67
MAINTENANCE AND LUBRICATION 8
Fluid Requirements
Quantity Type
Engine Oil (with filter) 5.1 liters 1.12 Imp gals 1 US gals 10-30W (see specification below)
Hydraulic Oil (with filter) 40 liters 6.4 Imp gals 10 US gals Total Equivis ZS46 (ISO VG 46)
Radiator Coolant 7.6 liters 1.67 Imp gals 2.0 US gals 50% Anti-Freeze
Fuel
28.7 liters 6 Imp gals 7 US gals
Unleaded Gasoline minimum
87 octane (91 RON)
Engine Oil: Must meet A.P.I. standard CJ or higher
TEMPERATURE VISCOSITY
More Than 25°C (77°F) SAE30, SAE10W-30, SAE10W-40
0°C to 25°C (32°F to 77°F) SAE20, SAE10W-30, SAE10W-40
Less Than 0°C (32°F) SAE10W, SAE10W-30, SAE10W-40
Tyre Pressure
Product
Front Wheel Rear Wheel
Tyre Size Tyre Type Tyre Pressure Tyre Size Tyre Type Tyre Pressure
3WD,
Treaded
Tire Option
22 x 12.00 - 12 Grassmaster 4pr
Minimum
0.7 bar (10 psi)
Maximum
1.37 bar (20 psi)
22 x 12.00 - 12 Grassmaster 4pr
Minimum
0.7 bar (10 psi)
Maximum
1.37 bar (20 psi)
3WD,
Smooth
Tire Option
22 x 12.00 - 12 Smooth 4pr
Minimum
0.7 bar (10 psi)
Maximum
1.37 bar (20 psi)
22 x 12.00 - 12 Smooth 4pr
Minimum
0.7 bar (10 psi)
Maximum
1.37 bar (20 psi)
Lubrication Points (Grease Every 50 Hours)
A. Tie Rod Ball Joints (1). D. Yoke Pivot Assembly (3).
B. Steering Cylinder Ball Joints (1). E. Rear Roller (6).
C. Lift Arm Pivot (3).
SERVICE INTERVAL CHART
Interval Item Section
First 25 hours • Roller bearings 8.13
First 50 hours
• Yoke pivots
• Rear roll bearings
• Rear roller adjusters
8.14
Every 40 hours • Levers, pivot points any friction points 8.14
