35
> Change from previous revision
AR331
Item Part No. Qty. Description Serial Numbers/Notes
1
4399316 1 Engine, Kubota D1105-E4B
2 5003476 1 • Gasket, Exhaust
3 553020 1 • Gasket, Muffler
4 554482 1 • Muffler
5 674600 2 U-Clamp, M8-1.25 x 38 mm
6 4378129 1 Head, Pipe
7 4387057 1 Cover, Exhaust
8 450168 2 Screw, M6-1 x 12 mm Hex Head
9 450171 2 Screw, M6-1 x 16 mm Hex Head
10 450216 2 Screw, M10-1.5 x 35 mm Hex Head
11 450389 4 Washer, M6 x 12.5 x 1.8
12 450390 4 Washer, M8 x 17 x 1.8
13 450391 2 Washer, M10 x 21 x 2.2
14 450410 4 Lock Washer, M6 x 9.6 x 1.5
15 450411 4 Lock Washer, M8 x 12.75 x 2
16 450194 4 Screw, M8-1.25 x 35 mm Hex Head
17 001339050 8 Nut, M8-1.25 Hex Staytite
18 450454 2 Nut, M10-1.5 Hex Flange
19 4378128 1 Tailpipe
To Next Page
