59
> Change from previous revision
AR331
Item Part No. Qty. Description Serial Numbers/Notes
1
4371246 1 Ram
2 4381788 8 Plastic Bearing, Unit Carrier
3 4387168 4 Treaded Rod, Shift Ram
4 452734 4 Washer, M16 x 48 x 4
5 450327 2 Hex Nut, M16 - 2 Grade 8
6 450382 2 Hex Nut, M16 - 2 Grade 8, Nyloc
7 450454 8 Hex Bolt, M10 - 1.5 x 90 Grade 10
8 450040 8 Hex Bolt, M10 - 1.5 x 90 Grade 8.8
9 452437 4 Hex Nut, M10 Flange Nyloc
10 4224901 10 AV Washer, 10.7 x 21 x 2.5
11 4169021 1 Weight Transfer And Lift Valve
12 4173283 1 Valve CXP23969
13 4399852 1 Hydraulic Valve Bracket
14 339979 1 Fitting, -6 ORFS x -6 ORB Straight
339909 1 • O-Ring, -6 ORFS
339897 1 • O-Ring, -6 ORB
15 450009 2 Hex Bolt, M6 - 1 x 70 Grade 8.8
16 450026 2 Hex Bolt, M8 - 1.25 x 90 Grade 8.8
17 450214 2 Hex Screw, M10 - 1.5 x 25 Grade 8.8
18 4258312 2 AV Washer, 8.7 x 13.5 x 2.5
19 450452 2 Hex Nut, M6 - 1 Grade 10
20 4399929 1 Cylinder Mounting Bracket
21 669506 8 Tube, Side Shift Clamp
22 4420830 1 Side Shift Tube Left Side
23 4420835 1 Side Shift Tube Right Side
24 340026 1 Fitting, 6-6 Straight Thread 45°
25 340061 2 Fitting, -6 ORFS x -6 ORB 90°
339909 1 • O-Ring, -6 ORFS
339897 1 • O-Ring, -6 ORB
26 674169 1 Side Shift Plate
27 4420842 1 Tube, Presssure Line-Lift Valve Not Shown
To Next Page
