Jacobsen AR331 - Page 67

67
> Change from previous revision
AR331
Item Part No. Qty. Description Serial Numbers/Notes
1
UK450031 8 Hex Head Bolt, M10 - 1.5 x 45 MM LG
2 UK450050 1 Hex Head Bolt, M12 - 1.75 x 50 MM LG
3 UK450104 2 Hex Head Bolt, M20 - 2.5 x 160 MM LG
4 UK450215 4 Hex Head Screw, M10 - 1.5 x 30 MM LG
5 UK450216 2 Hex Head Screw, M10 - 1.5 x 35 MM LG
6 UK450377 2 Hex Nut M6 - 1.0
7 UK450379 33 Hex Nut M10 - 1.5
8 UK450380 1 Hex Nut M12 - 1.75
9 UK450383 2 Hex Nut M20 - 2.5
10 UK450389 2 Washer, M6 x 12.5 x 1.8
11 UK450391 35 Washer, M10 x 21 x 2.2
12 UK450393 12 Washer, M16 x 30 x 3.3
13 UK450394 4 Washer, M20 x 37 x 3.3
14 UK450553 3 Pan Head Screw M8 - 1.25 x 25 MM LG
15 UK451500 2 Spirol Pin, 8 x 60
16 UK452436 3 Hex Flange Nut, M8
17 452585 10 Carriage Bolt, M10 - 1.5 x 25 MM LG
18 452586 8 Carriage Bolt, M10 - 1.5 x 30 MM LG
19 460050 4 Cotter Pin, 3/16 x 1 - 1/4”
20 670760 1 HOC Bracket Weldment, LH
21 670761 1 HOC Bracket Weldment, RH
22 671266 2 Yoke Bracket
23 671564 1 Rear Deck Pin Weldment, LH
24 671565 1 Rear Deck Pin Weldment, RH
25 673585 1 Stamped Deck Shell, 27”
26 673608 1 Discharge Chute
27 673611 1 Rear Hoc Bracket Weldment
28 673617 1 Baffle Weldment
29 673807 2 Fab Outer Brace Plate
30 673844 1 Rear Hoc Bar Weldment
31 674112 2 Clevis Pin, M16 x 107 MM LG
32 674211 6 Coach Bolt Spacer
33 674382 1 Rear Arm Assembly, LH
34 673609 1 • Rear Arm
35 674931 1 • Rear Arm Boss
36 UK450411 3 • Lock Washer, M8 x 12.75 x 2
37 UK450725 3
• Hex Head Socket Cap Screw, M8 - 1.25
x 30 MM LG
38 676387 1 • Oilite Bush
39 674383 1 Rear Arm Assembly, RH
40 673609 1 • Rear Arm
41 674931 1 • Rear Arm Boss
42 UK450411 3 • Lock Washer, M8 x 12.75 x 2
43 UK450725 3
• Hex Head Socket Cap Screw, M8 - 1.25
x 30 MM LG
44 676387 1 • Oilite Bush
45 3007764 1 Blade Washer, 1/2
