21
Midsize
Classic
ITEM PART NO. DESCRIPTION QTY
ITEM PART NO. DESCRIPTION QTY
FIGURE 1
ENGINE DECK ASSEMBLY
4130478-01
1-1 4130320 CAP-FUEL GASOLINE 3.5 1
1-2 4116345 TANK-FUEL 1
(INCLUDES ITEMS 3 & 4)
1-3 4132325 GROMMET-FUEL TANK 1
1-4 38540 S FUEL SHUT-OFF VALV 1
1-5 88042N HOSE CLAMP 2
1-6 48016-11A S HOSE-.25ID X 26" LG 1
48016-11A IS A SERVICEABLE LENGTH OF 26"
(USE 8" ON 933011 & 934011)
(USE 14" ON 933012 & 934012)
1-7 38666 FILTER, FUEL 1
1-8 4130483 S-36 FRAME WLDMT 1
(USED ON MODELS 933011& 933012)
1-9 4130482 S-48 FRAME WLDMT 1
(USED ON MODELS 934011& 934012)
1-10 4127203 TRANSMISSION-5 SPD 1
1-11 64123-15 BLT-HEX 3/8-16X3/4 4
1-12 64163-31 WASHER
(USE QTY 6 ON 933011 & 934011)
(USE QTY 10 ON 933012 & 934012)
1-13 64006-03 LOCKWSHR-HELICAL 3/8 4
1-14 64018-5 BLT-CRG 3/8-16X1-3/4 1
1-15 64139-21 BLT-WLF 3/8-16X3/4 1
1-16 4128952 ENGINE-KOHLER 15HP 1
2722215 OIL FILTER
2722216 AIR FILTER PAPER ELEMENT
2722217 FILTER FOAM PRECLEANER
1-17 4130269 ENGINE-B&S 15 HP 1
4130856 OIL FILTER
4130863 AIR FILTER PAPER ELEMENT
4130864 FILTER FOAM PRECLEANER
1-18 38460 PULLEY-ENGINE 1
1-19 64163-07 1-1/32X1-3/4X1/4 WASH 1
1-20 38542 CLAMP-DOCU TUBE 2
1-21 64006-01 LOCKWSHR-HELICAL 1/4 2
1-22 64123-89 BLT-HEX 1/4-20 X 3/4 2
1-23 38061A COVER 2
1-24 2306144 S DOCU TUBE W/LAB 1
1-25 64164-19 KEY WOODRUFF.19X.75 #9 1
1-26 64044-1 SCREW-SET 1/4-20X1/4 2
(ITEMS 27 - 29 USED ON 933011 & 934011 ONLY)
1-27 64163-29 WASHER-21/64 X 1 X 11GA 4
1-28 64205-003 BLT-MET M8-1.25X30 4
1-29 64006-02 LCKWSHER-HELICAL 5/16 4
1-30 64229-03 LOCKNUT-NYLON 3/8-16 1
1-31 2308000 PULLEY-IDLER 4.00 EOD 1
1-32 64144-01 SNAP RING 5/8 1
1-33 128175 PULLEY-SNGL GRV 7 ED 1
1-34 2721796 BELT-MIDSIZE GEARBOX 1
1-35 38304-03 BRG-FLANGED PLASTIC 1
1-36 64123-155 BLT-HEX 7/16-20 X 3 1
1-37 64006-06 LOCKWSHR-HELICAL 7/16 1
1-38 64123-54 BOLT, 5/16-18X3/4 HEX 2
1-39 64229-02 LOCKNUT-NYLON 5/16-18 2
1-40 64164-12 1/4X1/4X1 SQ END KEY 1
1-41 2721331.7 WLDMT-CLUTCH STOP MID 1
1-42 4121540 PIN-CLUTCH 1
1-43 64163-51 WSHR.453X1.38X7GA 1
(ITEM 44 USED ON 933012 & 934012 ONLY)
1-44 64197-005 BLT-TDFM 3/8-16X1-1/4 4
1-45 2721110 CLUTCH-ELECTRIC 1
(INCLUDES ITEM 46)
1-46 2720949 ASSY-CLUTCH WIRE 1
1-47 64271-01 WASHER-SQUARE HOLE 1
1-48 64002-04 LOCKWASHER, EXT. 5/16 1
1-49 * 4121560 KIT-BRK POLE RPLCMNT 1
1-50 64163-61 WASHER 1
* NOT ILLUSTRATED
