23
Midsize
Classic
ITEM PART NO. DESCRIPTION QTY
ITEM PART NO. DESCRIPTION QTY
FIGURE 2
TRANSMISSION DRIVE
4130478-02
2-1 2721382.7 LEVER-SHIFT 1
2-2 2722621 S-GEAR SELECTOR PLATE 1
2-3 64044-2 SCREW-SET 5/16-18X3/8 2
2-4 4130483 S-36 FRAME WLDMT 1
(USED ON MODELS 933011& 933012)
2-5 4130482 S-48 FRAME WLDMT 1
(USED ON MODELS 934011& 934012)
2-6 64018-15 BLT-CRG 5/16-18X1 2
2-7 64151-3 3/8-24 HH LOCKNUT 1
2-8 64229-02 LOCKNUT-NYLON 5/16-18 2
2-9 64163-46 WSHR.383/.393X.88X7GA 1
2-10 64229-01 LOCKNUT-NYLON 1/4-20 4
2-11 2721381.7 LEVER-SHIFT LOWER 1
2-12 2188155 GRIP-1/4X1X4-1/2 1
2-13 128108 WASHER PEERLESS 1
2-14 64139-08 BLT-WLF 5/16-18X3/4 4
2-15 64141-6 NUT, 5/16-18 1
2-16 64168-2 COTTER-HAIRPIN .08X1.19 4
2-17 2722033 SWITCH-NEUTRAL 1
2-18 85010N ZERK, 1/4-28 SELF THREAD4
2-19 2308135 COUPLER 2
2-20 64164-19 KEY WOODRUFF.19X.75 #9 2
2-21 4130099 SHAFT-CONNECTOR 2
2-22 64144-01 SNAP RING 5/8 2
2-23 35033-5A JACKSHAFT SHLD 3 2
2-24 64123-68 BOLT-HEX 5/16-18X1 1
2-25 2308133 SPRING-EXTENSION 2
2-26 64123-70 BLT-HEX 3/8-16X1-1/2 2
2-27 64141-4 NUT-WLF 3/8-16 18
2-28 38213 BEARING-JACKSHAFT 2
2-29 64123-89 BLT-HEX 1/4-20 X 3/4 4
2-30 2303056 SPACER-SPRING 2
2-31 2721853 SPACER-19.05x10.31x27LG 2
2-32 2308000 PULLEY-IDLER 4.00 EOD 2
2-33 4129467 SPACER-10.3X18.8X108 4
2-34 64123-138 BLT-HEX 3/8-16X3-3/4 4
2-35 64123-93 BLT-HEX 3/8-16X5 4
2-36 2721369.2 COVER-BELT BOBCAT 2
2-37 * 4128705.7 WLDMT-LH BELLCRANK 1
2-38 4128985.7 WLDMT-RH BELLCRANK 1
2-39 4127203 TRNSMSN-5 SPD W/ REV 1
(SEE FIGURE 4 FOR PARTS BREAKDOWN)
2-40 64163-29 21/64x1x11GA.WASHER 10
2-41 2721477 BELT-HB 56.75 2
2-42 38456 PULLEY-SLOTTED J-SHFT 2
2-43 4128652.7 WLDMT-MIDSIZE AXLE 1
2-44 4124853 DRUM-BRAKE 2
2-45 4128899 ASSY-WHL, 4PLY 13x6.50-6 2
(INCLUDES ITEMS 46 & 47)
2-46 * 38098A S TIRE 13X6.5X6 4-PLY 1
2-47 * 4128899-03 BEARING-BALL, 1" 2
2-48 64163-03 WSHR-.256IDX.62DX18GA. 2
2-49 64163-64 WASHER A/R
2-50 64163-07 WASHER, 1-1/32x1-3/4x1/4 2
2-51 64163-02 WASHER-11GA 4
2-52 64221-1 E CLIP 2
2-53 38534 BAND-BRAKE 2
2-54 64144-31 SNAP RING 2
2-55 4117094 LINK-BRAKE 4
2-56 33138-01 PIN, CLEVIS .47 2
2-57 4130590 ARM-BRAKE 2
2-58 33004A SWIVEL 2
2-59 33135-01 ROD-BRAKE 2
2-60 64197-021 BLT-TDFM 5/16-18 X 1.75 8
2-61 33138-07 PIN-CLVS GRVD .38 X 1.25 2
2-62 64144-30 SNAP RING.375 4
2-63 38322.7 PULLEY 9" 2
2-64 33278 SCRAPER-SINGLE EDGE 2
2-65 64123-50 BOLT-HEX 3/8-16X1 6
2-66 32599.7 SPACER-9" PULLEY 2
2-67 64229-03 LOCKNUT-NYLON 3/8-16 4
2-68 64006-03 WASHER, 3/8 HELICAL LCK 2
2-69 4130588 SPACER-BRAKE 2
2-70 64163-31 WASHER, 25/64X1X12 2
* NOT ILLUSTRATED
