25
Midsize
Classic
ITEM PART NO. DESCRIPTION QTY
ITEM PART NO. DESCRIPTION QTY
FIGURE 3
UPPER HANDLE ASSEMBLY
4130478-03
5-1 64175-01 PUSHNUT-3/16 ROD 2
5-2 2721495.7 WLDMT-UPPER HANDLES 1
5-3 2721505 SWITCH-PTO 1
5-4 64168-2 HAIRPIN COTTER 6
5-5 33103 SWIVEL 2
5-6 * 4128705.7 WLDMT-LH BELLCRANK 1
5-7 4128985.7 WLDMT-RH BELLCRANK 1
5-8 4122110 ROD-TRACTION CNTRL GD 2
5-9 38009N GRIP, TRACTION CNTRL 2
5-10 38360 GRIP-RECESSED 1 IN 2
5-11 * 2308121 ADHESIVE-3 GRAM TUBE 1
(USE WITH ITEM 10)
5-12 31032 LEVER,TRACTION CNTRL 2
5-13 64188-34 PIN-CLEVIS 3/16 X 2 2
5-14 64163-31 WASHER 2
5-15 64229-02 LOCKNUT-NYL 5/16-18 4
5-16 33288 STUD-DOUBLE ENDED 2
5-17 33288 SPACER 2
5-18 64229-01 LOCKNUT NYL 1/4-20 4
5-19 64061-37 PIN-ROLL 2
5-20 38189 SPRING COMPRESSION 2
5-21 2722426 GRIP-TRACTION LOCK 2
5-22 2308002 BRG-RADIAL W/THD STD 4
5-23 62464-5A WASHER,THRUST 5/16x3/4 2
5-24 2722722 LATCH-ROLLER RH GD 1
5-25 * 2722721 LATCH-ROLLER LH GD 1
5-26 64163-55 WASHER .328X.75X14 GA 2
5-27 64123-50 BLT-HEX 3/8-16 X 1 4
5-28 38148 SWITCH-ENGINE STOP 1
5-29 64152-46 SCREW-SLT HH 10-24X1/2 2
5-30 2306097 WLDMT-ACTUATOR - PLTD 1
5-31 38371-01 BRG-NYLINER 3/8 2
5-32 64025-15 NUT-HEX #10-24 KEPS 2
5-33 38357-08 CONTROL-THROTTLE 1
(ITEM 33 USED ON 933011 & 934011 ONLY)
5-34 38357-03 CONTROL-THROTTLE 1
(ITEM 34 USED ON 933012 & 934012 ONLY)
5-35 64197-015 BLT-TDFM 10-32X1/2 TORX 2
5-36 38383 SWITCH-N.C. 1
5-37 64152-23 1/4-20X3/8 LG SP SCREW 4
5-38 4131326 S-PANEL BOBCAT W/LABEL1
5-39 2188178 SWITCH-RETAINER 1
5-40 2308152 LEVER-OP LH 1
5-41 2308153 LEVER-OP RH 1
5-42 64197-002 BLT-TDFM 1/4-20X3/4 4
5-43 33030-09 IDLER-BUSHING 2
5-44 2303023 CONNECTOR-OP 2
5-45 64229-03 LOCKNUT-NYL 3/8-16 4
5-46 4130483 S-36 FRAME WLDMT 1
(USED ON MODELS 933011& 933012)
5-47 4130482 S-48 FRAME WLDMT 1
(USED ON MODELS 934011& 934012)
5-48 2308037 SPRING, TORSION OP 1
* NOT ILLUSTRATED
TRACTION LOCK ASSY'S ARE ALSO AVAILABLE
P/N 2722685 RH & P/N 2722684 LH
(INCLUDES ITEMS 15-23 & 24 OR 25)
