27
Midsize
Classic
ITEM PART NO. DESCRIPTION QTY
ITEM PART NO. DESCRIPTION QTY
FIGURE 4
PEERLESS TRANSMISSION
4130478-04
4127203 PEERLESS TRANS MODEL 700-070A
(COMPLETE UNIT AVAILABLE THRU
JACOBSEN)
(INDIVIDUAL COMPONENTS AVAILABLE
THROUGH PEERLESS 1-800-558-5402)
4-1 772083A COVER,TRANSMISSION 1
4-2 780086A BEARING,NEEDLE 1
4-2A 780142 BEARING,NEEDLE 1
4-3 770061A CASE,TRANSMISSION 1
4-4 776134 COUNTERSHAFT 1
4-8 792089A SHIFT KEY 4
4-9 784266 COLLAR,SHIFT 1
4-10 784376 ROD & FORK ASSY,SHIFT 1
4-11 778154 GEAR,BEVEL (42 TEETH) 1
4-12 778176 PINION,BEVEL (14 TH ST) 1
4-20 792077A BALL,STEEL,5/16" 1
4-21 792078 SET SCREW,3/8-16 X 3/8 1
4-22 792079 SPRING 1
4-24 780071 BEARING,THRUST 1
4-25 792073A SCREW,1/4-20 X 1-1/4 6
4-27 792035 RING,RETAINING 1
4-28 788040 RING,RETAINING 1
4-29 780072 WASHER 6
4-30 780108 WASHER 5
4-32 792001 “O” RING 2
4-34 780105A BUSHING,FLANGED 2
4-45 *2308007 NEUTRAL SWITCH NC 1
4-49 778146A GEAR,SPUR (37 TEETH) 1
4-50 778125 GEAR,SPUR (35 TEETH) 1
4-51 778239A GEAR,SPUR (32 TH ST) 1
4-52 778124A GEAR,SPUR (30 TEETH) 1
4-53 778123A GEAR,SPUR (25 TEETH) 1
4-56 778145 GEAR,SPUR (12 TH ST) 1
4-57 778151 GEAR,SPUR (15 TEETH) 1
4-58 778240 GEAR,SPUR (18 TH ST) 1
4-59 778126A GEAR,SPUR (20 TEETH) 1
4-60 778127A GEAR,SPUR (25 TEETH) 1
4-65 780139 WASHER,THRUST 1
4-66 776135 SHAFT,INPUT (3-11/16") 1
4-67 776402 SHIFTER & BRAKE SHAFT 1
4-71 788069 SEAL,SQUARE CUT 1
4-72 792074 THREADED PLUG 1
4-81 786081 CHAIN,ROLLER #41 1
4-82 786082 SPROCKET (9 TEETH) 1
4-83 786083 SPROCKET (18 TEETH) 1
4-90 788067B GREASE (32 OZ BENTONITE)
4-150 510334 GASKET ELIMINATOR
(LOCKTITE #515)
4-178 786176 COUPLING 1
4-179 776401 CONNECTOR SHAFT 1
(ITEMS 178 & 179 ARE OPTIONAL)
* NOT ILLUSTRATED
SEE YOUR PEERLESS DEALER FOR
REPLACEMENT PARTS.
