29
Midsize
Classic
ITEM PART NO. DESCRIPTION QTY
ITEM PART NO. DESCRIPTION QTY
5-1 112111-02 BLADE 18.00 OFFST HLFT 2
5-2 128169 PULLEY, IDLER 5.50 1
5-3 4110580.7 WLDMT-IDLER 1
5-4 4124108 S CASTER SUPPORT 2
5-5 4130209 PULLEY-B, 6.13 E.O.D. 2
5-6 2721323 S-ASSY SPINDLE 6 SHORT 2
(INCLUDES ITEMS 7-11)
5-7 38348-01 BEARING-SPINDLE SEALED2
5-8 33179-02 SPINDLE-SHORT 1
5-9 2721096 HOUSING-SPINDLE 6 HOLE 1
5-10 64144-38 SNAP RING 1
5-11 38315 NUT-SPINDLE 1
5-12 4128848 BELT-36 MIDSIZE 1
5-13 33049-05 BOLT-BLADE 2
5-14 38219 SPRING-TENSION 1
5-15 2722458 KNOB-4 PRONG 5/16-18 3
5-16 64259-01 U-NUT MULTITHREAD 5/16 3
5-17 64229-03 LOCKNUT-NYLON 3/8-16 15
5-18 4116661 PIN-PIVOT 1
5-19 4128851.2 COVER-36 BELT 1
5-20 4131477.2 CHUTE-DECK, 32-54 SD 1
5-21 810149 BUMPER, RUBBER 1
5-22 4120257.2 BRKT-CHUTE SUPPORT 1
5-23 4130483 S-36 FRAME WLDMT 1
5-24 64141-4 NUT-WLF 3/8-16 10
5-25 64006-05 LOCKWSHR-HELICAL 1/2 1
5-26 64262-012 BLT-FLG HD 3/8-16 X 1-1/4 12
5-27 64025-16 NUT-HEX 5/8-18 2
5-28 64123-05 BLT-HEX 1/2-20X1-1/2 1
5-29 64221-04 E-RING.875 1
5-30 64139-21 BLT-WLF 3/8-16X3/4 8
5-31 64123-50 BOLT-HEX 3/8-16X1 5
5-32 64123-88 BOLT, 3/8-16X2-3/4 HEX 1
5-33 64163-12 .635/.640X1.0X.25 WASH 4
5-34 64163-16 WSHR-41/64X1-3/8X12GA 2
5-35 64209-03 SPRING WASHER.67 ID 2
5-36 64163-65 WASHER-.890X1.375X18GA 1
5-37 64164-12 KEY-1/4X1/4X1 SQ END 2
5-38 4115864.7 BAFFLE-DISCHARGE 1
5-39 64018-3 BOLT-3/8-16X1 CARRIAGE 1
5-40 64268-03 NUT-FL NYLON LCK 3/8-16 2
5-41 108074-13 FLEX TRIM 44.38" 1
(USE 26" ON 36" DECKS)
FIGURE 5
36" DECK
4130478-05
