31
Midsize
Classic
ITEM PART NO. DESCRIPTION QTY
ITEM PART NO. DESCRIPTION QTY
6-1 112111-01 BLADE 16.25 OFFST HLFT 3
6-2 128169 PULLEY, IDLER 5.50 3
6-3 4110580.7 WLDMT-IDLER 1
6-4 4124108 S CASTER SUPPORT 2
6-5 2308140 PULLEY-ENGINE 3
6-6 2721323 S-ASSY SPINDLE 6 SHORT 3
(INCLUDES ITEMS 7-11)
6-7 38348-01 BEARING-SPINDLE SEALED2
6-8 33179-02 SPINDLE-SHORT 1
6-9 2721096 HOUSING-SPINDLE 6 HOLE 1
6-10 64144-38 SNAP RING 1
6-11 38315 NUT-SPINDLE 1
6-12 4128718 BELT-48 MIDSIZE 1
6-13 33049-05 BOLT-BLADE 3
6-14 38219 SPRING-TENSION 1
6-15 2722458 KNOB-4 PRONG 5/16-18 3
6-16 64259-01 U-NUT MULTITHREAD 5/16 3
6-17 64229-03 LOCKNUT-NYLON 3/8-16 21
6-18 4116661 PIN-PIVOT 1
6-19 4128731.2 COVER-48 BELT 1
6-20 4131477.2 CHUTE-DECK, 32-54 SD 1
6-21 810149 BUMPER, RUBBER 1
6-22 4120257.2 BRKT-CHUTE SUPPORT 1
6-23 4130482 S-48 FRAME WLDMT 1
6-24 64141-4 NUT-WLF 3/8-16 10
6-25 64006-05 LOCKWSHR-HELICAL 1/2 1
6-26 64262-012 BLT-FLG HD 3/8-16 X 1-1/4 21
6-27 64025-16 NUT-HEX 5/8-18 3
6-28 64123-05 BLT-HEX 1/2-20X1-1/2 1
6-29 64221-04 E-RING.875 1
6-30 64139-21 BLT-WLF 3/8-16X3/4 8
6-31 64123-50 BOLT-HEX 3/8-16X1 9
6-32 64123-88 BOLT, 3/8-16X2-3/4 HEX 1
6-33 64163-12 .635/.640X1.0X.25 WASH 6
6-34 64163-16 WSHR-41/64X1-3/8X12GA 3
6-35 64209-03 SPRING WASHER.67 ID 3
6-36 64163-65 WASHER-.890X1.375X18GA 1
6-37 64164-12 KEY-1/4X1/4X1 SQ END 3
6-38 113086 SPACER 2
FIGURE 6
48" DECK
4130478-06
6-39 64229-05 LOCKNUT, 1/2-13 NYLON 2
6-40 64123-72 BLT-HEX 1/2-13X2-1/2 2
6-41 4120208.7 BAFFLE-DISCHARGE 32-48 1
6-42 64268-01 NUT-FL NYLON LCK 1/4-20 2
6-43 4114063.7 BAFFLE-48 FRONT LH 1
6-44 2720784.7 BAFFLE-FRONT RH 1
6-45 64018-2 BLT-CRG 1/4-20X3/4 2
6-46 64268-03 NUT-FL NYLON LCK 3/8-16 7
(KIT #970281 INCLUDES ITEMS 42-46 &
(2) ITEM 26, (6) ITEM 31)
6-47 108074-16 FLEX TRIM 16" 1
