35
Midsize
Classic
ITEM PART NO. DESCRIPTION QTY
ITEM PART NO. DESCRIPTION QTY
8-1 2721110 CLUTCH-ELECTRIC 1
(INCLUDES ITEM 2)
8-2 2720949 ASSY-CLUTCH WIRE 1
8-3 2722033 SWITCH-NEUTRAL 1
8-4 38148 SWITCH-ENGINE STOP 1
8-5 108208 SWITCH DBL POLE 1
8-6 148082-10 FUSE 10 AMP 1
8-7 2721505 SWITCH-PTO 1
8-8 4131486 HARNESS-MDSZ CLASSIC 1
(INCLUDES ITEM 6)
FIGURE 8
BRIGGS & STRATTON ELECTRICAL DIAGRAM
4130478-08
