Jacobsen MR1 Series Quick Start Guide

QUICK START GUIDE
en-17
WARNING SERVICE REQUIRED
When this screen is shown, the machine
needs a service.
Go to the main menu and select service
menu, time until service to show the items
needed for a service.,
The number in the top right of the screen
indicates the total number of faults recorded.
Press the button below the  to confirm the
fault.
WARNING SOLENOID FAULT
When this screen is shown, there is a
solenoid fault.
Go to i/o diagnostics for solenoid
identification.
The number in the top right of the screen
indicates the total number of faults recorded.
Press the button below the  to confirm the
fault.
WARNING TST FAULT
When this screen is shown, there is a fault
with the TST. Stop as soon as possible and
contact your local Ransomes Jacobsen
Dealer
The number in the top right of the screen
indicates the total number of faults recorded.
Press the button below the  to confirm the
fault.
WARNING MAXIMUM SLOPE ANGLE
EXCEEDED
When this screen is shown, the maximum-
slope angle has been exceeded.
The number in the top right of the screen
indicates the total number of faults recorded.
Press the button below the  to confirm the
fault.

1
!
SERVICE
REQUIRED

1
!
FAULT SOLENOID

1
!
TST
™

1
0°
Slopes > = 22°
in either x or y
VISUAL DISPLAY
