14
> Change from previous revision
PGM
Item Part No. Qty. Description Serial Numbers/Notes
1
303873 1 Washer
2 309756 1 Sprocket,
3 365658 4 Spacer, Engine Mounting
4 400194 4 Screw, 5/16-18 x 1-3/4” Hex Head
5 306369 1 Screw, 5/16-24 x 1” Hex Head
6 434029 3 Screw, 1/4-20 x 1” Socket Head
7 441677 4 Carriage Bolt, 5/16-18 x 1-1/2”
8 443106 4 Nut, 5/16-18 Hex
9 443820 1 Nut, 1/2-20 Hex Jam
10 446130 3 Lockwasher, 1/4 Heavy
11 446136 8 Lockwasher, 5/16 Heavy
12 446154 1 Lockwasher, 1/2 Heavy
13 463003 1 Key, 1/2 x 1/8” Woodruff
14 503532 1 Engine, 4HP Honda
15 320774 1 • Key, 3/16 x1-1/2” Square
16 4108643 1 Spring, Throttle Plate
17 4135990 1 Torque Clutch Engages at 2000 RPM
18 4136546 1 Clutch Shaft, PGM
19 4136549 1 Guide, Cable
20 4136554 1 Collar, Cable Stop
21 1 • Set Screw, #6-32
22 4137299 1 Set Screw, #6-32 x 3/16” Cup
23 400218 2 Screw, 5/16-24 x 1/2” Hex Head
24 400108 4 Screw, 1/4-20 x 3/4” Hex Head
25 444708 4 Locknut, 1/4-20 Center
26 2811846 1 Engine Base Includes Decals
27 4148539 1 Cover, Clutch Includes Decal
28 REF 1 Cable, Bail Throttle See 2.1
29 REF 1 Cable, Paddle Throttle See 2.1
30 453009 2 Flat Washer, 5/16
31 4147695 1 Throttle Cover Includes Decal
