18
> Change from previous revision
PGM
Item Part No. Qty. Description Serial Numbers/Notes
1
1000477 1 Hub, L.H. Wheel
2 338766 1 • Bearing
3 366705 2 • Seal
4 1000476 1 Hub, R.H. Wheel (Includes 2 and 3)
5 366697 4 Bushing
6 366718 1 Collar, Latching
7 445801 1 Nut, 5/8-18 Hex Jam Lock
8 361451 1 Washer
9 164056 2 Band, Brake
10 366742 2 Pin, Brake Band
11 415513 2 Screw, 1/4-20 x 1/2” Socket Set
12 461389 2 Pin, 7/32 x 1-1/4” Roll
13 3004621 2 Sleeve, Clutch
62293 1 Pneumatic Transport Tires Optional Kit
14 5002905 1 • Wheel
15 360111 1 • Valve
16 554847 1 • Tire
17 434049 3 • Screw, 5/16-18 x 2” Socket Head
18 271920 1 • Spacer, Wheel
19 366719 1 • Latch
20 366716 3 • Spacer
21 366704 1 • Spring
22 452004 6 • Flat Washer, 5/16
23 444718 3 • Locknut, 5/16-18 Center
