It is the responsibility of the installer/owner to ascertain
compliance with specic local regulations prior to installa-
tion. Jacuzzi Europe S.p.A. gives no guarantee in this respect
and declines all responsibility regarding the compliance of
the installation performed.
Technical Features
The Delos/Delos Pro/Delos Pro Sound spa (0 1; 0 2) has a
capacity of about 860 litres. Its power supply is single-phase
(220/240 V), and all its electromechanical organs and pipes are
contained within its perimeter. Delos is equipped with a 2-speed,
2-Hp pump.
Delos Pro/Delos Pro Sound is equipped with a 2 Hp pump and a
recirculating pump.
The skimmer contains 2 ltering cartridges (ltering surface: 9.3
m
2
) which guarantee optimal water ltration.
Maximum absorption of the system
DELOS
(k): at 230 V (single phase) - (j): absorbed power
(x): see Chapter. “Electrical preparations”
DELOS PRO/ DELOS PRO SOUND
• VERSION WITH HEATER
Power supply
(single-phase)
Hydro total
consumption +
ltering + heater
Blower
(Pro Sound)
Audio System
(Pro Sound)
Spa-Pak
(optional)
Volt
220-240 ~ 50 23 (k) 5,15 (j)
0,6 (j)
0,25 (j) 2,5 (k)
Hertz Ampere kW kW kW Ampere
0,5 (j)
kW
• VERSION WITH EXCHANGER
Power supply
(single-phase)
Hydro total
consumption
+ ltering
Blower
(Pro Sound)
Audio System
(Pro Sound)
Spa-Pak
(optional)
Volt
220-240 ~ 50 8,8 (k) 1,95 (j)
0,6 (j)
0,25 (j) 2,5 (k)
Hertz Ampere kW kW kW Ampere
0,5 (j)
kW
(k): at 230 V (single phase) - (j): absorbed power
The electrical system that powers the spa must absolutely be
sized for maximum consumption (as shown in the table).
Heat exchanger (optional)
- Primary inlet MAX temperature ................................................50 °C
- Connections ...................................................................................... 3/4”
- Primary circuit ow rate ........................................................ 38 l/min
- Primary pressure drop ................................................... 0,271 M H
2
O
Weights
Net weight average volume
of use
water volume
MAX
Total max. weight
kg litres litres kg
~ 250 ~ 860 ~ 1390 ~ 1640
area
involved
support
area
average load
on concerned area
concentrated load
on support area
m
2
m
2
kg/ m
2
kg/ m
2
~ 3,65 ~ 3,57 ~ 449 ~ 459
User safety
n If installed by qualied personnel in compliance with the in-
structions in the enclosed installation manual, the system does
not present any risks for the user. However, safety is also contin-
gent upon appropriate use, according to the provisions in the
respective manual, while the user must delegate the operations
described in the installation manual to qualied personnel.
n It is important to make sure that personnel tasked to install
or manage the system are qualied as per legal requirements in
eect in the country where installation is carried out.
Arrangement for installation
n Models equipped with a Performance ltering group
The ltering assembly (spa-pak) can be located anywhere, but
not more than 4 m from the mini-pool. If installation is outdoors
(in very cold areas), it is recommended to provide valves that al-
low for complete drainage of the pipes that connect the spa to
the spa-pak.
If necessary, the spa-pak can be installed on a lowered surface
(with respect to the spa) with a maximum height dierence of
1m. Greater height dierences may reduce the ow rate of the
ltering pump.
The spa-pak must be installed so that it is cannot be accessed by
individuals without using keys, and protected from water and
inclement weather (an adequate ventilation must be provided).
n You can use a garden hose to ll the spa.

If the spa is connected, for periodic lling, to the
mains system that supplies drinking water, this con-
nection must be carried out in compliance with the
EN1717 norm, using “AA”, “AB” or “AD” anti-pollution
protection procedures. For further information, we
recommend you contact your water supply company
and/or your plumber.
n The customer must make provisions for a ground drainage
point of suitable dimensions and that can be inspected for any
cleaning that may be required.
Spa-Pak
(optional)
2,5 (k) 0,5 (j)
Ampere kW
Power supply (x)
(single-phase)
Total consumption electric heater
+ hydromassage + ltering
Audio System
(optional)
Volt
220-240 ~ 50 16 (k) 3,5 (j) 0,25 (j)
Hertz Ampere kW kW
