3
8
38°C
tap
diverter
thermostatic mixer
release button
Rotate to select the desired function
Rotate the knob and select the desired temperature.
Rotate the diverter to align with the symbol denoting the desired function.
To carry out the "water temperature test", select the function or the function and
open the tap.The water will come out of the nozzle under the seat (Frame 100-120) or from
the shower (Frame in2). It is possible to adjust the temperature by turning the mixer knob.
Each jet can be tilted by pressing the nozzle and moving it in the desired direction.
The maximum temperature of the mixed water must never exceed 45°C!
Press to select temperatures which exceed 38°C
Brassware
