Jacuzzi J-300 Series User Manual

55
Red
Red (Hot)
Pigtail
Neutral Bus
Ground
TB2
TB1
Black
Black (Hot)
White
Green
GFCI Sub Panel*
Main Panel*
Hot Tub Load Box
2-Pole
GFCI
Breaker
Ground
Main Panel with Secondary GFCI Shut-Off Box Using a
2-Pole GFCI Breaker with 3-Wire Grounded Connection
(4 Wires to Hot Tub, 2-Hot, 1-Neutral, 1-Ground)
D
Red
Red (Hot)
Pigtail
Neutral Bus
Ground
TB2
Black
Black (Hot)
Green
GFCI Sub Panel*
Main Panel*
Hot Tub Load Box
2-Pole
GFCI
Breaker
Ground
No Load Neutral Wire
Main Panel with Secondary GFCI Shut-Off Box Using a
2-Pole GFCI Breaker with 2-Wire Grounded Connection
(3 Wires to Hot Tub, 2-Hot, 1-Ground)
C
TB1
White (Neutral)
Green (Ground)
White (Neutral)
Green (Ground)
Load Neutral Lug on Breaker
*GFCI Sub Panel commonly
used when recommended GFCI
does not install in Main Panel.
*GFCI Sub Panel commonly
used when recommended GFCI
does not install in Main Panel.
Note: service disconnect not
shown in this diagram.
Note: service disconnect not
shown in this diagram.
W B R
BR

Jacuzzi J-300 Series Specifications

General

Series	J-300 Series
Shell Material	Acrylic
Dimensions	84" x 84" x 36"
Water Capacity	350 gallons
Pumps	2
Lighting	LED lighting
Water Management	ClearRay Active Oxygen System
