Jacuzzi J-315 - Electrical Wiring Instructions

19
Jacuzzi J-315J-315
Diverter Valve / Air Control Diagram
Seat Depths
A = 26.50” (67.3cm) Listed Dimensions
B = 28.00” (71.1cm) Represent Distance from
C = 27.00” (68.6cm) Top of Acrylic to Lowest
D = 28.00” (71.1cm) Point in Seat.
E = 27.75” (70.5cm)
Dimensions/Specifications Subject to Change Without Notice
Spa Operation Subject to
Change without Notice
A
Air Control 2:
Opens / Closes
Air Inlet to Jet
Group B.
A
B
Air Control 1:
Opens / Closes
Air Inlet to Jet
Group A.
B
Jet Selector:
Directs Jet Pump1
Output Between
Jet Groups A & B.
Front
Back
A
C
B
E
D
