Jacuzzi J-400 - J-425 Massage;Waterfall Selector Diagram

36
J-400
9.17 J-425 Massage/Waterfall Selector Diagram
100
6:45p
1b
1b
1b
2
1a
1a
1a
1a
3
3 3
1
a
b
4
4
Massage Selector
• Massage selector 1 diverts jets pump Nº 1 output between jet groups
1a-1b.
Jets Without Massage Selector Controls
• Jets (2) are always on when jets pump Nº 1 is running.
• Jets (3) are always on when jets pump Nº 2 is running.
Waterfall Selector
• Waterfall selector (4) controls circulation pump output to waterfall.
Spa operation subject to change without notice
