Massage Selector
• Massage selector 1 diverts jets pump Nº 1 output between jet groups
1a-1b.
Jets Without Massage Selector Controls
• Jets (2) are always on when jets pump Nº 1 is running.
• Jets (3) are always on when jets pump Nº 2 is running.
Waterfall Selector
• Waterfall selector (4) controls circulation pump output to waterfall.
