It is the responsibility of the installer to choose the
materials in relation to their use, to carry the work out
correctly, to check the condition of the system to
which the appliance is to be connected and its suit-
ability, and to guarantee safety when in use, for main-
tenance operations and system inspection.
I spa products are Class “I” appliances and so they must be fas-
tened securely, without intermediate joins, to the electric mains
and to the protection system (earth system).
The electric system of the building must be provided
with a 0.03A differential switch and an efficient pro-
tection circuit (earth).
Check that the differential switch is working correctly
by pressing the test button (TEST), which must click.
몇
Parts incorporating electrical components, except
remote control devices, must be located or fixed
so that they cannot fall into the spa.
Live components and equipment must be out of
reach of individuals in the spa.
I F or electrical connections, the installation of a multiple-pole section
switch is compulsory (
i
4), which must be positioned in a place that
complies with safety regulations and, in any case, which cannot be
reached by those using the spa.
It is mandatory to comply with this instruction. Any other
procedure is prohibited.
I The disconnection devices must be installed in the power supply
network according to the installation instructions.
I The installation of electrical devices and appliances (sockets, switch-
es, etc.) near the spa must conform to the regulations and the norms in
force in the country where the spa is installed.
I F or equipotential connection in compliance with specific national reg-
ulations, the installer must use the provided terminal (EN 60335.2.60
standard) on the electric wiring bo x (
i
4), marked by the symbol
.
In particular, equipotential connection must be carried out for all
metal parts surrounding the mini-pool, for example, the water and
gas pipes and any surrounding metal under-frames etc.
I The appliance comes equipped with an LED lighting system, in com-
pliance with Regulation EN 62471:2009.
CAUTION! Before carrying out any maintenance opera-
tion, disconnect the appliance from the power supply
line.
Il incombe à l'installateur ou au propriétaire de s'assurer
de la conformité du lieu d'installation aux dispositions
locales en vigueur avant de procéder à cette dernière.
La Jacuzzi Europe S.p.A. ne fournit aucune garantie à
cet égard et décline toute responsabilité quant à la
conformité de l'installation effectuée.
Caractéristiques techniques
La mini-piscine spa mod. Oxia (
i
1;
i
2) dispose d'une
pompe à deux vitesses de 2 Hp.
Le skimmer contient une cartouche filtrante assurant un filtra-
ge optimal de l'eau (la surface filtrante est de 2,3 m
2
).
Oxia Performance : dans ce cas, l'action filtrante est garan-
tie par un filtre à sable (fourni à part, avec une pompe de recy-
clage et une base de support, voir le manuel d'installation cor-
respondant).
Consommation maximum de l'installation
Le réseau électrique qui alimente le spa doit impérativement
être dimensionné pour une consommation maximale (tel qu'indi-
qué dans le tableau).
Poids
Sécurité d'utilisation
I A condition d'être installé par un personnel qualifié dans le res-
pect des dispositions figurant dans la seconde partie du manuel,
l'appareil n'expose l'utilisateur à aucun risque. La sécurité dépend
néanmoins du respect des instructions d'utilisation figurant dans la
première partie. Pour les opérations décrites dans la seconde par-
tie l'utilisateur doit s'adresser à un technicien qualifié.
I Il est important de s'assurer des compétences du personnel c har-
gé de l'installation ou du contrôle de l'installation conformément aux
dispositions des normes en vigueur dans le pays d'installation.
I P our les éventuelles interventions d'entretien exceptionnelles et/ou
les réparations, s'adresser à un Centre d'assistance agréé et veiller à ce
que soient exclusivement utilisées des pièces détachées d'origine.
Préparation pour l'installation
I Oxia est dotée d'une évacuation (voir
i
1, détail 1;
i
3, détail B).
Il incombe au client de veiller à l'installation d'un collecteur d'éva-
cuation de dimensions suffisantes et disposant dun regard per-
mettant de procéder le cas échéant à son nettoyage.
I Oxia Performance : il faut aussi prévoir le raccordement à
l'évacuation pour les périodiques contre-lavages et l'éventuel
vidage du filtre à sable monté sur le spa-pak, ainsi que le rac-
cordement hydraulique et électrique entre le spa-pak et la spa
(voir le manuel d'installation correspondant).
poids sans emballage
volume moyen
d’utilisation
volume d’eau
maximal
poids max.
total
kg
litres
litres
kg
~260
~ 880
~ 1100
~ 1360
surface d'appui
charge concentrée
sur la surface d'appui
m
2
kg/m
2
~2,67
~ 510
50/60
Alimentation (x)
Volt
16
(k)
2,5
(k)
3,5
(j)
0,5
(j)
Hertz Ampères
kW
Ampères
kW
(k): a 230 V
(x): voir “Opérations préalables
au branchement électrique”
(j): puissance absorbée max.
Consom. tot. disp. chauff.
élect. + hydromassage
Spa-Pak
(en option)
220-240~
