JIF-2002 WEIGHING INDICATOR&CONTROLLER
10
3-1 Analog Input and A/D Conversion
◎Analog Input and A/D Conversion
Type JIF-2002
Input Sensitivity
≧0.3uV/D
ZERO Adjustment
Range
0 ~20mV
Load Cell Excitation
DC10V±1%，230mA, Remote Sensing.
Can be connected up to 8 350ΩLoad Cells
Non-Linearity 0.01 % F.S.
A/D Conversion Method
△Σ
A/D Resolution
≒1/1,000,000
A/D Conversion Rate
Approx. 120 Times∕Sec.
Max. Load Cell Input
Voltage
32mV
ZERO Temperature
Comp.
±(0.2μV + 0.001% of Dead Load)/℃
TYP
SPAN Temperature
Comp.
± 0.001% ℃ TYP
Max. Resolution
1/16,000 (JIF-2002 Resolution can reach
1/60,000 depending on load cell quality &
performance).
3-2 General
◎ General
Type JIF-2002
Power Requirements
AC 110V or AC 220V ±10%，
50∕60Hz, Approx. 17VA
Net weight
Approx. 3.2 kg﹝7.054 lb﹞
Operation Temperature
－10℃∼ 45℃
Maximum Humidity
85%﹝non-condensing﹞
Physical Dimensions
240 (D) ×190 (W) ×104(H) mm
