3-5 Panel Key Function Table
Key Function Function Position Status
Panel Key ZERO
Control I / O
Pin 25 +
(Pin 16 or 17)
ZERO
OP-02
（Command Mode）
Z Cr Lf
JIF-2002 returns to the
center of ZERO if the
weight value within F004
range.
Panel Key TARE
Control I / O
Pin 24+
(Pin 16 or 17)
TARE
OP-02
（Command Mode）
T Cr Lf
JIF-2002 witches to
NET mode, ZERO’s the
display and stores the
TARE weight in Memory.
Panel Key TARE CLEAR
TARE
CLEAR
Control I / O
Pin23 +
(Pin 16 or 17)
Clear TARE Value
Panel Key GROSS / NET
GROSS
OP-02
（Command Mode）
G Cr Lf
Shift to GROSS Mode
Panel Key GROSS / NET
NET
OP-02
（Command Key）
N Cr Lf
Shift to NET mode
Panel Key PRINT / ACC
PRINT
Control I / O
Pin19 +
(Pin 16 or 17)
Print or Output latest
Data
Panel Key PRINT / ACC
ACC
Control I / O
Pin20 +
(Pin 16 or 17)
Print Accumulator Value
ACC Panel Key ACC / CLEAR
Print Accumulator Value
TACC Annunciator ON
Panel Key ACC / CLEAR
CLEAR
Control I / O
Pin18 +
(Pin 16 or 17)
Clear Accumulator and
Count
Panel Key
SET
POINT/CODE
Code Input CODE INPUT
CODE
OP-02
（Command Key）
CCXX Cr Lf
Reset Set point data
Panel Key
SET
POINT/CODE
SET POINT
OP-02 S Cr Lf, SS Cr Lf
Setting Final, SP1, SP2,
Free Fall, Hi, Lo
