JIF-2002 WEIGHING INDICATOR&CONTROLLER
29
F 502
Loss-in-weight Absolute Value

0 Not read Absolute Value
1 BDI-2002 reads Absolute Value
F 503
Output current when display ZERO
0.0mA through 9.99mA
●Initial 4.0mA
F 504
Output current at Full Capacity
0.0mA through 9.99mA
●Initial 20.0mA
F 505
Output Volt when display ZERO
-2.5V through +59.9V
●Initial 00.0 V
F 506
Output Volt at Full Capacity
-2.5V through +59.9V
●Initial 10.0 V
4-3 CALIBRATION
1. Select FULL CALIBRATION：
STEP 1: Turn the Power Switch OFF on the rear panel. Slide the SET
switch to the set side.
STEP 2: Turn the power switch ON. The screen will show blinking
SELECT.
STEP 3: Please press GROSS/NET key and a blinking CAL will show
on the screen. Then press the ↵ key.
STEP 4: The screen will show F-CAL. Please press the ↵ key.
