JIF-2002 WEIGHING INDICATOR&CONTROLLER
30
﹝1﹞Setting Minimum Division
The display of di 1 shows the smallest division. Use the
or key to move through the available divisions.﹝1、2、5、
10、20、50﹞. Press the ↵ key to set the minimum division.
﹝2﹞Setting Decimal （ F000 will change---see 4-2 ）
The screen will show dp→ d000.000. A blinking decimal will
show on the screen. Use the or  key to move through the
available decimal
Point position. Press the ↵ key to set the
decimal position.
﹝3﹞Setting Maximum Capacity
When setting maximum capacity, the screen will show CAP
→C000.000. Use the or key to set the numeric value, Use
the or key to move through digits. Press the ↵ to finish
the step.
﹝4﹞ZERO Adjust
The Screen will display ZERO . Please move the calibration
mass and objects away on the Weighing device then press ↵
key. A display of . . . . . . . means finishing the Adjustment.
﹝5﹞SPAN Calibration
The screen will show SPAN . Press ↵ key and place your
calibration mass on the weighing device and input weight value.
Use theorkey to set the available value, and the or key
to move through digits. Please press the ↵ key to finish the
calibration. The screen will show . . . . . . . .
STEP 5 : The screen will show END .
Slide the SET switch to the original side.
