JIF-2002 WEIGHING INDICATOR&CONTROLLER
58
Pin 9
HI Output
NET Weight ＞ Final Weight + HI
Pin 8
LO Output
NET Weight ＜ Final Weight – LO
Pin 7
FINAL Output Built-In program Mode: send signal at
Final.
Pin 6
Motion Detection / Error
Output
1 F105 = 0: Output at Stable; Shorted
when motion. 2 F105 = 1: 1Error
occurred, 2over Zero Band range,
or3Over weight capacity or printer
error.
Pin3.
Pin4
Output 12V
Pin 1.
Pin2
Output Common
6-2 BATCHING MODES
◎ SERIAL ﹝RS-232﹞ OP- 02
F 200
Baud Rate
11200 BPS 2400 BPS
34800 BPS 49600 BPS
F 201
Parity 0 Non-parity Even Parity 2Odd Parity
F 202
Output Data
Same as display 2 Gross Weight 3 NET
Weight 4 TARE Weight 5 Gross Weight, NET
Weight, TARE Weight
F 203
Output Mode
Stream 2 Stable and auto print 3 Manual
Print Mode 4 Accumulate and Print
5 Command Mode
F 204
Output Format
Sending without Set point Code 1 Sending
with set point Code
To Next Page
