JIF-2002 WEIGHING INDICATOR&CONTROLLER
57
1Built-In program Mode,
start Batch Input
1Batching will be started when Pin 22
is short-circuit to COM1
Pin 22
2Customer Program-
control Mode set point
“data” abort read input
2When Pin 22 is short-circuit to
COM1, JIF-2002 will stop receiving
data from set points, keeping the
previous data.
1Built-In program Mode,
Abort the Batch (Pulse
Input)
1When Pin 21 is short-circuit to
COM1, the batch is aborted and
FINISH signal is sent, and the NET
weight will be accumulated.
Pin 21
2Customer Program-
control Mode Automatic
Free Fall Compensation
command (Pulse input).
2When Pin 21 is short-circuit to
COM1, JIF-2002 will estimate the free
fall value for the next batch, and the
NET weight will be accumulated.
Pin 20
Print Accumulator Accumulator will be printed when P20
short-circuited with COM1.
Pin 19
PRINT Input (pulse input) When FC01, F203=3, F401=3,
F302=2 shorted with COM1, Data will
be sent one time.
Pin 18
Clear Accumulated Value
and Count
(pulse input)
If this command is accepted, all the
accumulated weight and accumulated
count will be cleared.
Pin 17
or
Pin 16
Input Common (COM1)
◎OUTPUT SCREW DESCRIPTION
Screw Signal Name Description
Pin 13
ZERO BAND Output
GROSS Weight ≦ ZERO Band
Pin 12 SP1 Output
1Batching Mode: NET Weight ≧
Final Weight– SP1
2Loss-in-weight Mode: GROSS
Weight >SP1
Pin 11
SP2 Output
NET Weight ≧ Final Weight– SP2
Pin 10
Free Fall Output
NET Weight ≧ Final Weight– Free
Fall
