James Loudspeaker | 535 Airpark Road, Napa, CA 94558 | 707.265.6343 | www.JamesLoudspeaker.com
20170811
WEDGE SERIES INSTALLATION GUIDE
8
Finally, tighten down the three set screws, with
the hex key we have provided, located on the
bottom of the speaker.
The speaker should sit flush with the wall and/or
ceiling before proceeding to the next step.
7
8
Once you have the speaker mounted into place,
then lift the speaker from the bottom and use a
fist to pound the speaker back into the wall in
order to make the speaker flush.
Now, mount the speaker onto the bracket by
guiding the upper channel of the speaker into
the top portion of the bracket.
7
10
9
Installation
Video
