56
57
ASSEMBLY OF THE WING
ASSEMBLY OF THE TIRES AND WHEELS
Step 1 Step 3Step 2
T
I
NS AN
T
G
L
U
E
*Apply instant glue into the groove of the wheel.
3x12mm
40542
16015
86056-White
86057-Yellow
86058-Orange
*Drill two 7mm holes for mounting.
Body Reamer (Not included)
40542
3x12mm
3mm
3mm
94004
3x12mm
Hex Screw
.....x2
94041
3mm
Nylon Nut
.....x2
Step 1
58
ASSEMBLY OF THE TIRE ONTO FRONT KNUCKLE AND REAR HUB
Assemble both right and left sides
.....x4
40550
Wheel Nut
*To tighten the wheel nut, use M-35
(17mm) wheel nut tool.
Step 2
80003-Revolver Proline M2
1/8 Tires(Option)
81098-Yellow
81099-Red
1/8 Inner Foam Donut(Option)
40240
*Assembled Tire and Wheel
40550
BAG
NO.2
NO.4
NO.4
BAG
10239 Ca Glue
