Mask the windows from

the inside with masking tape.

Paint the body with

polycarbonate spray paints.

Spray Paint

3x5mm

40539

Hole for fuel tank.

For the exhaust outlet

of the muffler.

8mm

Cut out for engine.

8mm

CUTTING OUT THE BODY AND PAINTING

ASSEMBLY OF THE REAR VIEW MIRROR

Cut out the body as shown.

Use a neutral detergent to

remove any dirt and oil.

MOUNTING THE NOSE PIECE

Step 1

3mm

3x8mm

Step 2

Cut Out

94041

3mm

Nylon Nut

.....x1

94001

3x5mm

Hex Screw

.....x2

94002

3x8mm

Hex Screw

.....x1

41110

Body(Option)
