LR
LINE IN
RL/LFE
LINE IN
RL/LFE
LR
LINE IN
RL/LFE
LINE IN
RL/LFE
Figure 2
Line Level Connections
Processor/Pre-Amp/
Receiver
PRE • OUT LFE OUTPUT
Left and Right pre-outs on Processor/Pre-Amp/Receiver connected to Left and Right
line inputs on subwoofer amplier
LFE Output on Processor/Pre-Amp/Receiver connected to LFE input on
subwoofer amplier
OR
Processor/Pre-Amp/
Receiver
