J&W JW-A780LM-D3 User Manual

- 31 -
AMD Series User's Manual
BIOS SETUP UTILITY
JUSTw00T!
DRAM Timing Configuration
Auto
Limit
Manual
←
Select Screen
↑↓
Select Item
+- Change Option
F1 General Help
F10 Save and Exit
ESC Exit
Memory Clock Mode
DRAM Timing Mode
Memory 2T Mode
[Auto]
[Auto]
[2T Mode]
v02.61 (C)Copyright 1985-2006, American Megatrends, Inc.
Options
BIOS SETUP UTILITY
JUSTw00T!
ECC Configuration Set the level of ECC
protection. Note: The
'Super' ECC mode
dynamically sets the
DRAM scrub rate so
all of memory is
scrubbed in 8 hours.
←
Select Screen
↑↓
Select Item
+- Change Option
F1 General Help
F10 Save and Exit
ESC Exit
ECC Mode
DRAM ECC Enable
DRAM SCRUB REDIRECT
4-Bit ECC Mode
DRAM BG Scrub
Data Cache BG Scrub
L2 Cache BG Scrub
L3 Cache BG Scrub
[User]
[Disabled]
[Disabled]
[Disabled]
[Disabled]
[Disabled]
[Disabled]
[Disabled]
v02.61 (C)Copyright 1985-2006, American Megatrends, Inc.
►
DRAM Timing Conguration
Click <Enter> key to enter its submenu.
・
Press <Esc> key to return to "JUSTw00T!" menu.
►
Memory Conguration
Click <Enter> key to enter its submenu.
• Memory Clock Mode
This item is to select the memory clock mode.
• DRAM Timing Mode
This item is to select the DRAM Timing mode.
• Memory 2T Mode
Available options: 1T Mode
，
2T Mode
，
Auto
・
Press <Esc> key to return to "JUSTw00T!" menu.
►
ECC Conguration
Click <Enter> key to enter its submenu.
