Model DP Oil-Fired Heater Page 27
Key Model ORDER
No. Description No. PART NO.
FIRE BOX & JACKET COMPONENTS
44 Burner Tube Gasket All R0392200
45 Burner Support Bracket All R0392300
46 Burner Compartment Door 3000 R0392402
47 Fire Box Plug Kit Contains: All R0392500
48 Fire Box Cover Plate
49 Fire Box Plug
50 Fire Box Plug Insulator
51 Gap Spacer (Return) All R0392600
52 Flue Collector Assembly 3000 R0392702
53 Flue Top Assembly 3000 R0392802
54 Inner Stack All R0392900
55 Flue Collector Shield 3000 R0393002
56 Vent Blade (10 included) All R0393100
57 Gap Spacer (In/Out) All R0393200
58 Hold Down Clip (2 RH and 2 LH included) All R0393300
59 Fire Box 3000 R0393402
60 Fire Box Cover (2 included) 3000 R0393502
OIL BURNER PARTS & COMPONENTS (Not Shown)
61 End Air Shutter All R0387800
62 Bulk Air Band All R0387900
63 Tube Gasket All R0388000
64 Motor, 1/7 H.P. , 3450 RPM All R0388100
65 Blower Wheel 4- 1/4 x 3- 7/16 All R0388200
66 Flexible Coupling All R0388300
67 Fuel Unit, Two Stage All R0140100
68 Pump Outlet Fitting All R0388400
69 Connector Tube Assembly All R0388500
70 Ignition Transformer All R0140200
71 Contact Spring Terminals All R0388600
72 Air Tube Combination All R0388700
73 Nozzle Line Electrode Assembly All R0393900
74 Electrode Rod & Tip All R0393600
75 Burner Head & Screws 3000 R0389500
76 Delavan Nozzle, 2.25 3000 R0362400
77 Primary Control All R0140300
78 Honeywell Cad Cell All R0389600
79 Fuel Unit Hardware Kit Contains R0393700
By-Pass Plug All
By-Pass Plug All
1/8 Burner Head Plug All
1/4 Burner Head Plug All
OPTIONAL EQUIPMENT
80 Pressure Relief Valve, 3/4" NPT, 75 PSI All R0040400
81 Chimney Cap - 9" All R0393800
