JANE BABYSIDE - Adjusting Features; Adjusting the Co-Sleeping Cot Height; Removing the Upholstery

10
Adjusting the height
To adjust the height of the co-sleeping cot, press the red button on the top part of the dial on the side of the cot
and then turn the dial until the red button is locked into a dierent position from its original one.
Each half circumference the dial is turned is a dierent height position.
There are 6 dierent positions.
*Note: The co-sleeping cot can be tilted with a maximum dierence of 2 positions between one side and the
other. The baby’s head should always be in the highest part of the cot.
Removing the upholstery
a) Remove the mattress and unfasten the Velcro strips on the bottom of the upholstery attached to the base
frame.
b) Unfasten the side zips next to the window, slide the buttons on each end of the detachable bar and remove it.
c) Unfasten the Velcro strips of the two side sleeves covering the vertical tubes.
d) Unfasten the zip found on the top frame of the cot and take the upholstery o completely.
