General
1. Intended use
The shredder is designed solely for shredding/chipping
all kind of newly cut tree branches of diameter up to 8.5 cm.
2. Restrictions
You should not use the shredder for shredding/chipping metal, stones, plastics. if you are going
to shred tree roots check that the diameter is less than 8.5 cm and remove all earth, sand
stones.
Before using the machine for the first time, check the maximum engine speed by screwing in/out
the screw which controls the position of the throttle lever so that it is positioned as in the diagram.
(fig.3) After the first hour’s use check that the bolts of the blades and counter blade are firmly
fixed and that the gap between blades and counter blade is 0.5mm(half a millimeter). Adjust in
the slots necessary and fix the bolts.(fig.2a,ab)
3. Description of the machine
The shredder is a machine for shredding/chipping newly cut wood. The rotor has 2 blades each
with a 30 cm width and is powered by a gasoline engine. Transmission is through two parallel
drive belts. The shredded wood or chips are discharged through the output tube by the
centrifugal force of the rotor. Because of the angle of the blades and the positioning of the
counter blade branches are pulled inside the machine automatically and feeder belt is
required.(fig.1)
