5. Installation Guide
1. Please insert SD memory card into
JANUS V2 SD card slut and connect with
bracket.
2. Connect with JANUS V2 ‘Video OUT’ component to display monitor’s
(or Navigation LCD) ‘Video INPUT’ component. (Yellow is video, red is audio)
3. Connect with cigar power cable to JANUS V2 power Component (DC 7~26V) for
operation the unit.
9 page
