Jastram ENGINEERING SCA 300 - Figure 5 - Indicator Terminal Block TB1 Configuration; Figure 6 - Non-Follow up Terminal Block TB2 Configuration

Installation
Page 13 of 31
Doc No.: MAN01502, 27-02-01 SCA 300 Manual
Terminal Block Installation
a) Refer to Figures 5 and 6. Lay out the terminal blocks and label the
required terminals. If optional non follow-up input device is not required
terminal block TB2 may be omitted.
INDICATOR TERMINAL BLOCK TB1
1 • SHLD (CABLE SHIELDING)
2 • +VDC (POSITIVE DC POWER SUPPLY FOR RAI BACKLIGHT)
3 • +ROI (RUDDER ORDER INDICATOR POSITIVE)
6 • -ROI (RUDDER ORDER INDICATOR NEGATIVE)
7 • +RAI (RUDDER ANGLE INDICATOR POSITIVE)
8 • -RAI (RUDDER ANGLE INDICATOR NEGATIVE)
9 • -VDC (NEGATIVE DC POWER SUPPLY FOR RAI BACKLIGHT)
NOTE: 1. TERMINAL BLOCK NOT SUPPLIED.
Figure 5 – Indicator Terminal Block TB1 Configuration
NON FOLLOW-UP TERMINAL BLOCK TB2 (OPTIONAL)
1 • FFU (NFU/FFU RELAY CONTROL)
3 • -COMM (NEGATIVE DC POWER SUPPLY)
7 • PORT (PORT RUDDER COMMAND)
9 • STBD (STBD RUDDER COMMAND)
NOTE: 1. TERMINAL BLOCK NOT SUPPLIED.
Figure 6 – Non-Follow Up Terminal Block TB2 Configuration
